- Available 2016-10-26
- Due 2016-11-04, 17:30 in your coursegit assignments repo
- See the assignment notes for the required repository structure.
Part 1: Rasterization and clipping
Given a polygon with vertices (in counterclockwise order):{(3, 5), (1, 7), (1, 1), (7, 6), (3, 5)}
- Find the Edge Table for the scan line algorithm
- Find the Active Edge Table for lines 4,5, and 6
- Clip the edges to the 3x3 viewport with lower left corner at (2,3); use the Cohen-Sutherland algorithm.
Part 2: Clipping Rays
Write a procedure (in pseudocode) to test whether a line P+t ũ
intersects an axis aligned rectangle lying on the z=0
plane. The
inputs to your procedure are P
, a point in space that does not lie
on the z=0
plane, ũ
, an arbitrary vector not orthogonal to the
z
-axis, and the bottom left and top right corners of the rectangle
to test against. If the line does not intersect the rectangle, then
the procedure should return a special value MISS
to indicate this,
and otherwise it should return the (x,y)
coordinates of the
intersection point.
